Distal Access Catheter

HW-Flex Distal Access Catheter

HW-Flex distal access catheter is designed to introduce interventional or diagnostic devices to peripheral and neuro vascular systems
The optimal combination of trackability and support -- the newly designed HW-Flex distal access catheter
Hi-way multi-layer fusion technology with multi-segment gradient design achieves a perfect balance for enhancing catheter system navigation through challenging anatomy and maximizing procedural stability or support
Flex composite material combined with HS hydrophilic coating promotes a smooth and atraumatic vessel interaction for an ideal deliverability
Thin wall catheter system design allows efficient 1:1 torque control and excellent kink resistance
0.071'' (1.80mm) lumen enabling dual device delivery for rapid primary access of today’s most complex therapies
  • Comparison between HF-Flex and other brands

    Manufacturers Brand ID (in) OD (in) Length (cm)
    Curatia HW-Flex 0.071 0.083 115, 125, 132
    Microvention Sophia plus 0.070 0.082 115, 125, 131
    Medtronic React 71 0.071 0.0855 132
    Stryker Catalyst 7 0.068 0.082 115, 125, 132
  • Order Information

    Catheter Size Length (cm) Order Number
    6F 115 5DA6ST1150
    125 5DA6ST1250
    132 5DA6ST1320
